API TR 6AF3

API TR 6AF3

Click here to purchase
Technical Report 6AF3 provides design guidelines for API 6BX style flanges utilized as end and outlet connectors in high-pressure, high-temperature (HPHT) surface and subsea applications.

For this document, HPHT applications are intended to mean flanges assigned a temperature rating greater than 350 °F or a pressure rating greater than 15,000 psi.

This document does not address thermal effects including gradient effects or subsea production equipment. Service temperature ratings above 550 °F (288 °C) are outside the scope of this technical report. The flange designer should address thermal effects when designing flanges rated for high temperatures.

Product Details

Edition:
1st
Published:
08/01/2020
Number of Pages:
34
File Size:
1 file , 2.1 MB
Product Code(s):
G6AF301, G6AF301
Note:
This product is unavailable in Cuba, Iran, North Korea, Syria
